Dây cáp âm thanh HELUKABEL HELUSOUND 400 Lautsprecherkabel | Black | 2 x 1.5 mm²

HEKUKABEL

Dây cáp âm thanh HELUKABEL HELUSOUND 400 Lautsprecherkabel | Black | 2 x 1.5 mm²

P/N:

(0) Bình luận

Thông tin chung:

All products of the HELUSOUND 400 LOUDSPEAKER series impress with their extremely high flexibility. 0,15 stranded wires and a very soft PVC
outer sheath make this possible. These cables are particularly used in mobile applications on stages, in studios or in the conference industry.

Liên hệ ngay

0909.039.539

Chia sẻ

Dây cáp âm thanh HELUKABEL HELUSOUND 400 Lautsprecherkabel | Black | 2 x 1.5 mm²

Application

All products of the HELUSOUND 400 LOUDSPEAKER series impress with their extremely high flexibility. 0,15 stranded wires and a very soft PVC
outer sheath make this possible. These cables are particularly used in mobile applications on stages, in studios or in the conference industry.

Mô Tả Sản Phẩm

Cable Structure

Conductor material:
Core insulation:
Core colours:
Sheath material:
Cable external diameter:
Sheath colour:

Copper, bare
PVC
rd, bk
PVC
approx. 6,6 mm
black

Electrical Data

Conductor resistance, max.: 12,7 Ohm/km

Technical Data

Weight:
Min. bending radius for laying:
Operating temperature range min.:
Operating temperature range max.:
Copper weight:

approx. 73,4 kg/km
33 mm
-10°C
+70°C
28,8 kg/km

Tải tài liệu kỹ thuật cho sản phẩm:

1DB_400089_en.pdf (0 lần tải)
